Manufacturer: AmeriGlide OEM Code:aavplc
$9,499.00
Free Shipping
The AmeriGlide Atlas Commercial Vertical Platform Lift comes standard with a package of accessories that help it meet a wide range of code requirements out of the box, especially the strict requirements for units over 60". These accessories include a pair of interlocks, an 18" toeplate, solid side walls, keyed remote call boxes, and an emergency alarm & light package.
The AmeriGlide Commercial lift can be configured to lift as high as 144 inches and has an optional battery backup.
The AmeriGlide Commercial lift can be configured to lift as high as 144 inches and has an optional battery backup.
Quick Stats
- Lifting Capacity: 550 lb
- Standard Lift Height: 96"
- Maximum Lift Height: 144"
- Portable: No
- Arrives Assembled: No
- Standard Drive System: Direct Worm-Gear & Screw-Nut
- Optional Drive System: None
- Battery Powered Option: Yes
- Constant Pressure Platform Controls: Yes
- Emergency Stop Platform Control: Standard
- Alarm Button: Standard
- Keyed Controls: Standard
- Call-Send Controls: One Direction with Key x2
- Keyed Call-Send Controls: Two Direction Toggle, Two Direction Toggle with Key
- Platform Type: Solid
- Standard Platform Size: 34" x 54"
- Optional Platform Sizes: 40" x 54"
- Standard Platform Configuration: Straight-Thru Access
- Optional Platform Configurations: Adjacent Access
- Upper Landing Gate: Optional
- Upper Access Ramp: None Available
- Lower Access Ramp: 18" Fixed Toeplate
- Grab Rail: Optional
- Guard Panel: Standard
- Maximum Stops: 3
Use our Virtual Lift Builder to visualize your lift.
