Manufacturer: ThyssenKrupp Access OEM Code:PL-S
$4,825.39
Free Shipping
The PL-S Standard Vertical Platform Lift offers a standard ballscrew drive or an optional batter powered hydraulic drive that offers higher lift speeds. A battery powered ballscrew drive is also available. The PL-S has the highest maximum lifting height of any lift we carry, 168 inches.
The PL-S comes equipped with a guard panel, grab rail, keyed call-send controls, and can be optionally configured with 90 degree access or same side access platforms.
The PL-S comes equipped with a guard panel, grab rail, keyed call-send controls, and can be optionally configured with 90 degree access or same side access platforms.
Quick Stats
- Lifting Capacity: 750 lb
- Standard Lift Height: 36"
- Maximum Lift Height: 168"
- Portable: No
- Arrives Assembled: Yes
- Standard Drive System: Ballscrew
- Optional Drive System: Hydraulic
- Battery Powered Option: Yes
- Constant Pressure Platform Controls: Yes
- Emergency Stop Platform Control: Standard
- Alarm Button: Standard
- Keyed Controls: Standard
- Call-Send Controls: Call-Send with Key
- Keyed Call-Send Controls: None Available
- Platform Type: Solid
- Standard Platform Size: 36" x 48"
- Optional Platform Sizes: 36" x 56", 36" x 60", 42" x 60"
- Standard Platform Configuration: Straight-Thru Access
- Optional Platform Configurations: 90 Degree Access, Same Side Access
- Upper Landing Gate: Optional
- Upper Access Ramp: None Available
- Lower Access Ramp: 31.5" Fixed
- Grab Rail: Standard
- Guard Panel: Standard
- Maximum Stops: 3
