Manufacturer: AmeriGlide OEM Code: CPL[400,600,800,1000,1200,1400]
$5,470.00
Plus Shipping
Quick Stats
- Lifting Capacity: 750 lb
- Standard Lift Height: 53"
- Maximum Lift Height: 171"
- Arrives Assembled: Yes
- Standard Drive System: 1" Diameter ACME Screw
- Optional Drive System: None Available
- Battery Powered Option: Yes
- Constant Pressure Platform Controls: Yes
- Emergency Stop Platform Control: Lighted Emergency Stop with Alarm
- Alarm Button: Lighted Emergency Stop with Alarm
- Keyed Controls: Optional
- Call-Send Controls: One Per Stop Included
- Keyed Call-Send Controls: Keyed and/or Wireless
- Platform Type: Solid with Non-Skid Coating
- Standard Platform Size: 36" x 54" (34" Usable Width)
- Optional Platform Sizes: 36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable)
- Standard Platform Configuration: Straight-Thru Access
- Optional Platform Configurations: Same Side Entry-Exit, 90 Degree Adjacent Access
- Upper Landing Gate: Optional
- Upper Access Ramp: None Available
- Lower Access Ramp: 36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding
- Grab Rail: Included
- Guard Panel: 42"
- Maximum Stops: 3
- Lift Speed (FPM): 10
- Other Options: Fire-Rated Doors, Automatic Door Openers
Documents
Use our Virtual Lift Builder to visualize your lift.
The Stratos VPL represents a new generation and evolution in VPL's. New technologies introduced in the Stratos VPL make this VPL series more reliable, easier to use, easier to service, easier to troubleshoot, and the premiere market choice for platform lift solutions.
Innovation is at the heart of this next generation Vertical Platform Lift. The Stratos VPL is an outstanding choice for vertical lifting solutions in the home or in light commercial settings where an elevator is impractical or unnecessary.
Features:
Innovation is at the heart of this next generation Vertical Platform Lift. The Stratos VPL is an outstanding choice for vertical lifting solutions in the home or in light commercial settings where an elevator is impractical or unnecessary.
Features:
- Guardian System: 4 bright, high-contrast LED status lights give continual performance feedback from the lift's control board. Monitoring almost every critical system, Guardian can provide immediate feedback and guidance.
- SteadyDrive: Ensures a smooth, quiet and stable lift.
- ReadyUPS System: True battery back-up option that can deliver at least 5-cycles in the event of power loss.
- Certifications: ETL listed, CSA B44.1/ASME A17.5, Safety standard ASME A18.1, Rated commercial and residential.
